3D model of a square MDF peg board with a grid of 484 holes and a hand slot at each corner

18 November 2026

484-hole peg board in 18mm MDF

MR MDF 18mm Drawn from a sketch

A sketch turned into a 3D model and a dimensioned drawing: 484 holes on a 50 mm grid in an 1190 x 1190 sheet of 18mm moisture-resistant MDF, with four hand slots.

Read →
3D model of a wall sculpture made of 40 plywood ribs forming a rolling wave on a mounting board

16 November 2026

Wave wall sculpture: 40 plywood ribs

Marine ply 15mm 3D design check

A 1.8 m wave wall sculpture built in 3D from a set of drawings: 40 ribs in 15mm ply on a mounting board, plus one change we suggested to make it easier to assemble.

Read →
Batch of bolt template assemblies in 17mm form ply fitted with hold-down bolts, ready for delivery

30 May 2026

Bolt templates in form ply

Film face form ply 17mm Bolt template

Bolt templates cut from 17mm film face form ply for a local steel fabricator — they lock the hold-down bolt pattern in place during the concrete pour for steel columns on construction projects across Townsville and beyond.

Read →
Stack of octagonal 9mm MDF bolt templates with an eight-hole flange pattern, alongside the customer's reference template in black

1 December 2025

Spliced pile bolt templates in 9mm MDF

MDF 9mm Bolt template

Eight-bolt octagonal templates — 20 cut in one batch from 9mm MDF for a major Townsville precast concrete manufacturer. Used to lock the splice flange bolt pattern during spliced pile fabrication.

Read →
Assembled gemstone lapping machine — bronze base plate, vertical post with dial gauge, orange polishing bowl, angle gauge and speed-controlled drive motor

18 November 2025

Precision aluminium parts for a gemstone lapping machine

Aluminium 5083 (marine grade) 16mm Precision aluminium parts

High-tolerance precision parts for a gemstone lapping machine — drilling, milling and profile cutting in 16mm 5083 marine-grade aluminium, run on our Multicam with the Unist Coolubricator.

Read →
An 18mm marine ply boat floor panel being cut on the Multicam

16 October 2025

Marine ply boat floor replacement

Marine ply 18mm Pattern from original

A boat floor panel rebuilt in 18mm marine ply — we measured the rotten original, drew it up in Fusion, and cut a perfect drop-in replacement on the Multicam.

Read →

Got a job like this? Send your DXF.
